Clustering Algorithms in VaSSTra

Source: vignettes/clustering-algorithms.Rmd
clustering-algorithms.Rmd

VaSSTra clusters twice, and they are different problems that call for different algorithms:

  1. States (step 1) group multivariate observations (one student at one time point, described by several indicators) into a small set of interpretable profiles.
  2. Trajectories (step 3) group whole sequences (one student’s ordered string of states over time) into groups of similar journeys.

The first is ordinary multivariate clustering on a numeric matrix; the second is clustering on a matrix of pairwise sequence distances. This article explains the algorithms VaSSTra offers for each, when to reach for them, and how the automated selection chooses.

States: from indicators to profiles

step1_states() (and vasstra(..., variables = )) turns the standardized indicator matrix into n_states profiles. The state_method argument picks the algorithm; states are then ordered from the lowest to the highest average standardized profile, so the labels read low-to-high.

Latent profile analysis (the default)

method = "lpa" fits a Gaussian finite mixture model with mclust: each state is a multivariate Gaussian, and every observation gets a posterior probability of belonging to each state rather than a hard assignment. lpa_model selects the covariance structure. The default "EEI" (equal variances, zero covariances, tidyLPA model 1) is diagonal and equal across states, the most parsimonious choice. Because it is a probability model, the number of states can be compared by BIC, and classification quality by entropy and the posterior probabilities (fit_indices()).

Use it when the indicators are roughly continuous and you want a model-based solution with soft assignments and information criteria. This is the common default in learning-analytics profile work.

fit <- vasstra(
  engagement,
  state_labels = c("Disengaged", "Average", "Active"),
  state_method = "lpa",
  lpa_model = "EEI"
)
#> Using n_states = 3 to match the supplied labels.
#> Selected n_trajectories = 3 (hamming + pam, silhouette = 0.435); see `diagnostics$selection`.
fit_indices(fit)
#> VaSSTra fit indices: states (lpa)
#>  n_states method lpa_model log_likelihood n_parameters   aic   bic sabic  caic
#>         3    lpa       EEI          -9940           34 19949 20120 20012 20154
#>    awe   clc   kic   icl entropy prob_min prob_max silhouette min_size max_size
#>  20461 20145 19986 20384    0.89     0.94     0.96       0.26      266      551
#>  size_ratio
#>         2.1

k-means

method = "kmeans" minimises the total within-cluster sum of squared Euclidean distances to cluster centroids (Hartigan–Wong). It is fast and familiar, gives hard assignments, and assumes roughly spherical, equal-spread clusters. It has no likelihood, so counts are compared by silhouette rather than BIC.

Use it when you want a quick, hard, centroid-based partition and the profiles are compact and similarly sized.

Partitioning around medoids (PAM)

method = "pam" (from cluster) is the medoid analogue of k-means: each cluster is represented by an actual observation (its medoid), and the algorithm minimises total distance to medoids. It is more robust to outliers than k-means and works from pairwise distances (here Euclidean on the standardized indicators).

Use it when you want k-means-style partitions but with more resistance to outliers, or a representative real profile per state.

CLARA and fuzzy clustering

Two more cluster partitioning methods sit alongside PAM. method = "clara" runs PAM on repeated samples of the data and keeps the best medoids, so it reaches PAM-like partitions on many more observations than PAM can handle directly. method = "fanny" is fuzzy: it assigns every observation a membership in each cluster rather than a single hard label, and VaSSTra then hardens those memberships to each observation’s nearest cluster so the rest of the workflow sees ordinary states.

Use clara when the data are large enough that PAM is slow; use fanny when you want a soft, membership-based grouping and are comfortable collapsing it to hard states.

Hierarchical clustering

VaSSTra offers both directions of hierarchical clustering. The divisive method method = "diana" (from cluster) starts with all observations in one cluster and splits recursively, which can separate a few large, clearly distinct groups more naturally than agglomeration. The agglomerative linkages "ward.D2", "ward.D", "complete", "average", "single", "mcquitty", "median", and "centroid" (base R hclust) build the tree bottom-up; all are cut at n_states. Ward minimises the increase in within-cluster variance at each merge and tends to give compact, balanced clusters; complete and average control the between-cluster linkage differently; single chains and is rarely what you want for profiles.

Use it when you want a dendrogram / nested structure, or a deterministic linkage rule; ward.D2 is the usual first agglomerative choice and diana the divisive alternative.

What automation does

Under n_states = "auto", VaSSTra compares two through six states and selects a recommendation (by BIC for LPA, by average silhouette for the hard methods). It never selects a solution whose smallest class holds under 5% of observations, the conventional threshold below which a latent class is treated as spurious. Supplying state_labels fixes the count directly.

Trajectories: from sequences to groups

step3_trajectories() (and vasstra()’s trajectory step) clusters the aligned state sequences. This is a two-ingredient recipe: a sequence dissimilarity turns every pair of sequences into a distance, and a clustering method groups the resulting distance matrix. Both are chosen explicitly.

Sequence dissimilarities

dissimilarity selects how two sequences are compared. The options capture genuinely different notions of “different”, so the choice is substantive:

Distance What it counts Good when
hamming Position-by-position mismatches on the aligned grid Timing matters: being in a different state at the same moment is what separates journeys
osa, lv, dl Edit distances: insertions, deletions, substitutions (and transpositions for osa/dl) to turn one sequence into the other Shape matters more than exact timing; small shifts should cost little
lcs Length of the longest common subsequence (the chapter’s default) Shared ordered sub-patterns matter, regardless of gaps between them
qgram Overlap of length-q substrings Local motifs (short recurring patterns) matter
cosine, jaccard Token-set overlap, ignoring order Only the composition of states visited matters, not their order
jw Jaro–Winkler string similarity Prefix agreement is important

hamming and lcs sit at the two ends most analyses use: when students are in each state versus what ordered pattern they follow. The chapter analysis uses lcs. Studer and Ritschard (2016) review how these measures differ and what each one privileges.

Clustering the distance matrix

method groups the distances: "pam" (medoids, outlier-resistant, a representative sequence per group), the agglomerative linkages "ward.D2" / "ward.D" / "complete" / "average" / "single" / "mcquitty" / "median" / "centroid", cut at n_trajectories. As with states, Ward favours compact balanced groups and PAM favours robustness; ward.D2 with lcs reproduces the worked chapter analysis.

fit <- vasstra(
  engagement,
  state_labels = c("Disengaged", "Average", "Active"),
  dissimilarity = "lcs",
  cluster_method = "ward.D2"
)
#> Using n_states = 3 to match the supplied labels.
#> Selected n_trajectories = 3 (lcs + ward.D2, silhouette = 0.514); see `diagnostics$selection`.
fit
#> VaSSTra Analysis
#>   142 subjects | 8 times | 3 states | 3 trajectories
#>   lcs + ward.D2 | silhouette 0.514

Backend

backend = "Nestimate" (default) computes the distances and clustering through [Nestimate::build_clusters()], which supports every distance and method above. backend = "base" is a dependency-free fallback that supports only hamming and lcs distances, useful for a minimal install.

Choosing among the candidates

Two verbs make the comparison explicit rather than automatic. state_choices() and trajectory_choices() fit a full grid of methods and counts and return one tidy row per candidate, with the recommendation marked within each method: silhouette for the hard clusterings and BIC for LPA (model-based criteria only compare within LPA). Nothing is selected silently; you fit the inspected candidate by its id.

state_options <- state_choices(
  engagement,
  n_states = 2:5,
  method = c("kmeans", "pam", "ward.D2", "lpa")
)
plot(state_options, metric = "silhouette")

Average silhouette width (Rousseeuw, 1987) is the shared diagnostic: for each unit it contrasts its average distance to its own group against the nearest other group, so higher is better-separated. BIC (Schwarz, 1978) trades model fit against the number of parameters and is only meaningful for the likelihood-based LPA. evaluate() and plot(evaluate(fit)) show the same silhouette on the same scale, so the method comparison here and the count comparison there compose into one argument.

When to use what: a short guide

  • Continuous indicators, want soft assignments and information criteria → LPA (default). Compare counts by BIC; check entropy and prob_min.
  • Quick hard partition, compact profiles → k-means.
  • Robustness to outliers / a representative profile → PAM.
  • Want a dendrogram or a deterministic rule → hierarchical ward.D2.
  • Trajectories where timing separates students → dissimilarity = "hamming".
  • Trajectories where the ordered pattern separates students → dissimilarity = "lcs" (the chapter default), with ward.D2 or pam.
  • Unsure → run state_choices() / trajectory_choices() across a few methods and let the silhouette (and BIC, for LPA) guide you.

References

The clustering is carried out by the packages VaSSTra depends on: mclust, cluster, and Nestimate, together with base R’s kmeans() and hclust(). Their canonical citations (from citation()) and the original method papers (from the corresponding help pages) are below, followed by two packages whose conventions VaSSTra follows without importing them.

Packages VaSSTra uses

  • Scrucca, L., Fraley, C., Murphy, T. B., & Raftery, A. E. (2023). Model-Based Clustering, Classification, and Density Estimation Using mclust in R. Chapman & Hall/CRC, ISBN 978-1032234953. doi:10.1201/9781003277965. LPA state estimation. See also Scrucca, L., Fop, M., Murphy, T. B., & Raftery, A. E. (2016). mclust 5: Clustering, Classification and Density Estimation Using Gaussian Finite Mixture Models. The R Journal, 8(1), 289–317. doi:10.32614/RJ-2016-021.
  • Maechler, M., Rousseeuw, P., Struyf, A., Hubert, M., & Hornik, K. (2026). cluster: Cluster Analysis Basics and Extensions. R package version 2.1.8.3. https://CRAN.R-project.org/package=cluster. PAM, CLARA, FANNY, DIANA, and silhouette.
  • Saqr, M., López-Pernas, S., & Misiejuk, K. (2026). Nestimate: Network Estimation, Bootstrap, and Higher-Order Analysis. R package version 0.8.4. https://github.com/mohsaqr/Nestimate. Sequence distances and trajectory clustering.
  • R Core Team (2025). R: A Language and Environment for Statistical Computing. R Foundation for Statistical Computing, Vienna, Austria. https://www.R-project.org/. k-means (kmeans) and hierarchical clustering (hclust).

Methods

  • Hartigan, J. A., & Wong, M. A. (1979). Algorithm AS 136: A k-means clustering algorithm (?kmeans).
  • Ward, J. H. (1963). Hierarchical Grouping to Optimize an Objective Function. Journal of the American Statistical Association, 58(301), 236–244. doi:10.1080/01621459.1963.10500845. The ward.D2 implementation follows Murtagh, F., & Legendre, P. (2014). Ward’s Hierarchical Agglomerative Clustering Method: Which Algorithms Implement Ward’s Criterion? Journal of Classification, 31(3), 274–295. doi:10.1007/s00357-014-9161-z (?hclust).
  • Kaufman, L., & Rousseeuw, P. J. (1990). Finding Groups in Data: An Introduction to Cluster Analysis. PAM, CLARA, FANNY, and DIANA (?pam, ?clara, ?fanny, ?diana).
  • Rousseeuw, P. J. (1987). Silhouettes: a graphical aid to the interpretation and validation of cluster analysis. Journal of Computational and Applied Mathematics, 20, 53–65. doi:10.1016/0377-0427(87)90125-7. (?silhouette).
  • Schwarz, G. (1978). Estimating the Dimension of a Model. Annals of Statistics, 6(2), 461–464. doi:10.1214/aos/1176344136. BIC.
  • Studer, M., & Ritschard, G. (2016). What Matters in Differences Between Life Trajectories: A Comparative Review of Sequence Dissimilarity Measures. Journal of the Royal Statistical Society, Series A, 179(2), 481–511. doi:10.1111/rssa.12125. On choosing a sequence distance.

Conventions VaSSTra follows (not dependencies)

  • van der Loo, M. (2014). The stringdist package for approximate string matching. The R Journal, 6(1), 111–122. doi:10.32614/RJ-2014-011. The definitions the sequence dissimilarities follow (osa, lv, dl, qgram, cosine, jaccard, jw).
  • Rosenberg, J., Beymer, P., Anderson, D., van Lissa, C. J., & Schmidt, J. (2018). tidyLPA: An R package to easily carry out latent profile analysis (LPA) using open-source or commercial software. Journal of Open Source Software, 3(30), 978. doi:10.21105/joss.00978. The “model 1” naming for the "EEI" covariance structure.

Method overview and the substantive analysis: VaSSTra chapter of Learning Analytics Methods and Tutorials.
